Product Parameter
|
Product |
curved laminated glass |
|
Thickness |
6.38mm 8.38mm 10.38mm |
|
Place of Origin |
Qinhuangdao, China |
|
Structure |
Solid |
|
Shape |
Flat or curved |
|
Size |
2440*1830mm,3300*2140mm,3300*2440mm,3660*2140mm,3660*2440mm,or customized |
|
Complete Range Of Size |
The laminated glass can meet the requirement of large area light |
|
Surface |
Smooth and flat surface and good vision |
|
Delivery and Package |
|
|
Delivery Details |
Within 25 working days after down-payment or by negotiation |
|
Packing |
1. Powder interleave between two sheets 2. Seaworthy plywood crates 3. Iron belt for consolidation |
Curved Tempered Glass Performance Characteristics
1.safety: When the qualified tempered glass is broken, the fragments are small, the number of fragments in the 50mmx50mm area is not less than 40, the fragment section is basically vertical to the surface, there is no sharp Angle, and it will not cause harm to people.
2. impact strength: withstand 1040g steel ball from 1 meter high free fall impact does not break.
3.bending strength: bending strength can reach 200ma.
4. optical properties: the optical properties of the glass do not change during the tempering process.
5. heat stability: at room temperature on the glass pouring molten lead liquid (327℃) glass does not break. The tempered glass is heated to 200℃ and put into 25℃ water without breaking the glass.
Application
Curved laminated glass can be used for lifting sightseeing elevators, shopping malls and hotels revolving doors. Bulletproof glass and anti-theft glass can be used in the business halls of financial companies such as banks, securities companies, insurance companies, as well as gold and silver jewelry shops, museums, commercial residential buildings, prisons and other places, counters, doors and Windows. PVB films produced with special formulas are also widely used in aerospace, military and high-tech industries, such as aircraft, spacecraft, and military
Customized Options
Different interlayer films: PVB / SGP / EVA laminated safety glass
Different glass types: clear/ultra clear/colored/reflective/low-e / frosted/mirror/patterned/AR/fluted laminated glass
Different shapes: Flat/curved/hot bent/square/rectangle/triangle/paralleled and other irregular shape laminated glass
Different strengthened: Standard size not-tempered float / custom size half-tempered / heat strengthened HS/heat soaked test HST laminated glass
Different processing: Silkscreen printing/digital printing/sandblasting/acid etching/engraving/hot melting/painting/gradient/metal mesh/wired/fabric/colorful/pdlc smart laminated glass
Different thickness:6.38mm, 8.38mm, 8.76mm, 10.76mm, 13.52mm, 17.52mm, 21.52mm, 3+3mm, 4+4mm, 5+5mm, 6+6mm, 8+8mm, 10+10mm, 12+12mm, 15+15mm, triple-layer, four-layer, other multi-layer laminated glass
Glass size: Custom cut to size, max size 3300x13000mm
Glass special processing: Polished edges, drill holes, cutouts, cut notches, logo printing, safety corners, and other client's required processing
Advantages: Safety glass, meets European CE EN12600 and American SGCC ANSI Z97.1 standard
Applications: Railings, balustrades, partitions, floors, windows, doors, canopies, skylight roofs, staircases, exterior curtain walls, etc.
Welcome to inquiry.
